AC Magnetic Contactor 9~95A

APC2 series AC contactor has a novel appearance and compact structure. It is used to frequently start and control AC motors, connect and break circuits over long distances, and can be combined with appropriate thermal overload relays to form an electromagnetic starter.

Send Enquiry
Model No.
APC2-09
APC2-12
APC2-18
APC2-25
APC2-32
APC2-38
Poles 3P
Rated Conventional Heating Current
Ith(A)
20
20 32 40 50 50
Rated Voltage Ui(V)
Ui(V)
690
Rated Operation Current Ue=380/415V
AC-3 Ie(A)
9 12 18 25 32 38
AC-4 Ie(A)
3.5 5 7.7 8.5 12 14
Power Controlled 3ph cage Motor AC-3
220/240V KW
2.2 3 4 5.5 7.5 8.9
380/415V KW
4 5.5 7.5 11 15 18.5
660/690V KW
5.5 7.5 10 15 18.5 18.5
Electrical life (x104operations)
AC-3
110 110 110 110 90 90
AC-4
22
Mechanical life (x104 operations)
1200 1200 1200 1000 1000 1000
Matched Fuse
Size
RT16-00
A
20
20
32
40
50
50
Main contact
3NO
Built-in auxiliary contact
1NO+1NC
