Voltage protection relay uses a high-speed and low power processor as its core. When the power supply line has over-voltage, under-voltage, or phase failure, phase reverse, the relay will cut off the circuit quickly and safely to avoid accidents caused by abnormal voltage being sent to the terminal appliance.
|
Monitoring Type
|
Three-phase Four-wire
|
|
Output Characteristics
|
SPDT
|
|
Over Voltage
|
0~20%
|
|
Under Voltage
|
0~20%
|
|
Time Delay
|
0.1~10S
|
|
Phase Sequence
|
√ |
|
Phase Failure
|
√ |
|
Asymmetric Voltage
|
5%~15%
|
|
Working Voltage/Frequency
|
L/N: AC127V-254V, 50/60Hz
|
|
Response Time of Relay
|
0.5S
|
|
Contact Rating
|
AC-15:3A/250VAC
|
|
Ambient Temperature
|
-10°C~+55°C
|
|
Voltage Error
|
⼠2% Max
|
|
Temperature Error
|
⼟2% Max
|
